Xzh Test New 35kv High Voltage Surge Generator Discharge Power 1225j

Name: Xzh Test New 35kv High Voltage Surge Generator Discharge Power 1225j
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHHV535-2L
Price: 1,050.00 USD
Availability: InStock

جزئیات محصول:

محل منبع:	چین
نام تجاری:	XZH Test
گواهی:	CE/ISO
شماره مدل:	XHHV535-2L

اطلاعات دقیق

محل منبع:

چین

نام تجاری:

XZH Test

گواهی:

CE/ISO

شماره مدل:

XHHV535-2L

برجسته کردن:

High Light

برجسته کردن:

35kv high voltage surge generator,high voltage discharge power generator,cable fault locator surge generator

high voltage discharge power generator

cable fault locator surge generator

Trading Information

مقدار حداقل تعداد سفارش:

1 دور

جزئیات بسته بندی:

جعبه چوبی

زمان تحویل:

5-8 روز کاری

شرایط پرداخت:

t/t

قابلیت ارائه:

2000 واحد در سال

توضیحات محصول

XHHV535-2L

Model NO.

XHHV535-2L

Usage

Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester

Power

Electricity

Certification

CE, ISO

Customized

Color

Black

Impact Voltage

0~35kv

High Voltage Partial Pressure

2.5

Built-in Capacitor

2μf

Output Voltage Polarity

Negative Polarity

Impact Power

400W

Overcurrent Protection

10A (More Than 3 Seconds)

Over-Temperature Protection

65ºC

Transport Package

Wooden Box with Foam Inside

Specification

540L× 300W× 450H

Trademark

XZH TEST

Origin

China Xi&an

Production Capacity

1000

Product Description

This device is an integrated unit that incorporates a DC high - voltage source, energy storage capacitor, discharge ball gap and so on. It effectively replaces the traditional test transformer, operating box and pulse energy storage capacitor, which used to weigh hundreds of kilograms.

★ With automatic protection functions for overcurrent, overvoltage and overheating;
★ High voltage pulse output is uniform and controllable;
★Super short-circuit protection function, which can make the high-voltage output directly short-circuit to ground;
★ It has dual 2.5-level pointer display for current and voltage, which is intuitive and clear, and the impact discharge process is clear at a glance;
★ High-voltage side voltage measurement, real-time and accurate;
★ It has zero start protection and potentiometer zero return output function, safe and reliable;
★ Unique high-voltage measurement design, in the stopped state, the voltmeter can indicate the capacitor voltage in real time;
★ The discharge time can be set arbitrarily within the appropriate interval;

Technical Parameters

Impact voltage	0~35kV
High voltage partial pressure	Level 2.5
Built-in capacitor	2μF
Output voltage polarity	negative polarity
Impact power	400W
Overcurrent protection	10A (more than 3 seconds)
Power	1225J
Over-temperature protection	65ºC
Volume	540L×300W×450H
Weight	no more than 25kg
Working power supply	AC 220V±10%/50Hz±2Hz
Ambient temperature	-20~+60ºC
